Capacity: 1 ton working load limit (WLL), fatigue‑tested at 1.5× WLL for enhanced reliability.
Standard lift height: 2.5 m as standard; available up to 5 m per the requested specification (customizable).
Safety brake system: Automatic double‑pawl brake with double guide rollers ensures fail-safe operation and reduced risk of slippage.
Grip & movement: Roll‑edge hand‑wheel housing and chain guides allow smooth, tangle‑free chain handling.
Construction: Heavy‑duty all‑steel, powder‑coated housing resists impact, dust, and weather exposure.
Hooks: Forged alloy-steel top and bottom hooks with 360-degree swivel and safety latches for secure rigging.
Standards & compliance: Safety factor ≥ 4:1; engineered to exceed EN 13157, ASME B30.16, and AS 1418.2 standards.
