Scanning Electron Microscopes (SEM) are high-resolution imaging instruments that use a focused beam of electrons to scan the surface of a specimen, producing detailed three-dimensional images of surface morphology and topography. SEMs provide information on texture, composition, and microstructure at nanometer to micrometer scales. Widely used in materials science, biology, electronics, and industrial quality control, SEM enables precise surface characterization, elemental analysis (with EDS), and structural studies. Modern SEM systems often include advanced detectors, variable pressure modes, and digital imaging for enhanced versatility and accuracy.
